PLC Omron CP1E kontrol Elektropneumatik

11:17410 summary words · ~2 min readEnglishBy MTech BasicTranscribed Jul 23, 2026
Analyze another video with Pro30-day money-back guarantee
Summary

The video demonstrates how to program an Omron CP1E PLC to control a pneumatic cylinder's automatic forward/backward motion with start/stop/emergency functions.

Understanding this PLC programming method enables precise automation of industrial pneumatic systems, improving operational efficiency and safety.

Section summaries

0:00-0:31

Intro / Sponsor

optional

The video opens with Islamic greetings and an overview of components: power supply, emergency/start/stop buttons, indicator lights, limit switches, and a 5/2 solenoid valve. The instructor states the project goal: automatic forward/backward cylinder control with PLC programming.

  • Identifies key hardware components for pneumatic PLC systems
  • Establishes learning objective for automated motion control

Contains essential component list but lacks technical depth

0:31-2:13

Hardware Setup

watch

Demonstrates connecting components to the PLC: power supply to 24V, emergency button to input 0.61, start button to 0.00, stop button to 0.01, limit switches to 0.03/0.04, and solenoid valve to 100.00/100.01. The instructor explains address assignments for each component.

  • Standard input/output address assignments for Omron CP1E
  • Proper grounding requirements for safety-critical components

Critical foundational information for subsequent programming

2:13-6:21

Programming Logic

watch

Details CX Programmer steps: creating new project (Ctrl+N), selecting CP1E/N20 CPU, programming START (input 0.00 → relay 200.1), STOP (input 0.01 → relay 200.2), and EMERGENCY (input 0.02 → relay 200.3). Shows relay-based sequencing for forward (relay 1) and backward (relay 2) motion with sensor-triggered transitions.

  • Relay address mapping for control logic
  • Sensor-triggered state transitions using A0/A1 inputs

Core programming content with actionable steps

6:21-9:03

Testing & Validation

watch

Demonstrates program transfer (Ctrl+T) to PLC, power-on sequence, and manual operation testing. Shows cylinder moving forward/backward automatically after START, stopping at limit switches, and emergency stop functionality with manual reset requirement.

  • Successful program transfer procedure
  • Physical system response validation

Essential verification of working automation system

9:03-11:02

Conclusion

optional

Instructor summarizes the pneumatic cylinder control system's operation: automatic bidirectional motion, position-limited stopping, and emergency shutdown. Ends with Islamic closing remarks.

  • System behavior summary
  • Safety protocol confirmation

Recaps known information without new technical content

Key points

  • PLC Wiring Configuration — The video shows wiring a 5/2 solenoid valve, emergency/start/stop buttons, limit switches, and indicator lights to the Omron CP1E PLC, using standard industrial components.
  • Program Structure Logic — The program uses relay-based logic where pressing START activates relay 1 (forward motion), relay 2 (backward motion) triggers after sensor A1 detection, and STOP/EMERGENCY interrupts the cycle via relay 3.
  • Emergency Stop Protocol — Emergency stops immediately halt cylinder movement and activate an emergency light (address 60.02), requiring manual reset to resume operation.
if the star is pressed then forward and backward automatically Instructor
relay 1 plus sensor A1 Instructor

AI-generated from the transcript. May contain errors.

0:00

Assalamualaikum warahmatullahi wabarakatuh see friends all on this occasion we will learn how to control the system or control the Pneumatic cylinder using the Omron VLC ok let's see the wiring we will line up later here we use the usual power supply 3 emergency start and stop buttons and the indicator light there are also 2 limit switch cylinders

0:31

one valve 5/2 double solenoid there are also the PLC omron compressor and air service unit for the question that we will work on this time is the automatic forward and backward cylinder of course with control star if the star is pressed then

0:59

forward and backward automatically forward and backward automatically and the start light on then if the stop stop is pressed then the cylinder stops at the minimum stop light on and the emergency cylinder stops when the emergency light is on and it is the input output, yes, this is the input address

1:28

and output for PLC Ombron if input is 0,0 if output is 100 okay, let's just make the program using CX programmer okay, click ctrl + N to open a new page ctrl + N okay, we choose the type of PLC that we will use, that is CP1E and the CPU type is N20

2:13

Okay, the program screen is open, usually to make it easier for us to make programs, we share the step by step, like this, start stop emergency, the first is start, if start is pressed, the start light will turn on, okay, we make start for input, this is how to call the input, click C, then we enter the address 00.00 start,

2:42

for output, click O, we will enter the address, we use the internal relay for the internal relay address, namely 200.0.200.1.200.2 and so on, okay click OK then we give the name relay start, we lock it so that it continues to activate

3:14

this LED Star is to activate the lamp, the lamp Star, the address is 100.02, the lamp Star, so that it is not confused, then the lamp Star is on, yes, for the next step, that is, the automatic return

3:44

we use a formula like this, A forward and A backward use different relays, that is, relay 1 and relay 2 for A forward relay 1 for A backward relay 2 to activate relay 1, the formula is star plus sensor A0 okay, we make A forward first, A forward, yes, forward cylinder, forward cylinder, okay, so star plus sensor A0, it means relay star

4:19

relay start + sensor A0, the address is 60.003 A0, okay activate relay 1 relay 1, we lock it, okay relay 1 is active, relay 1 is for what? relay 1 is for advancing the A-maju cylinder, this is relay 1, okay solenoid advanced, the address is 100.00 okay, 100.00

4:54

the cylinder is advanced, the next step is to use the relay 2 to activate relay 2, which is relay 1 plus sensor A1 relay 1 plus sensor A1, the address is 00.04 activate relay 2, we also lock

5:32

when the relay 2 is active then we disconnect relay 1 because the cylinder will go back disconnect relay 2, yes, automatically for the forward cylinder, it won't activate again relay 2 for the cylinder goes back disconnect the cylinder goes back 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.1, 0.

6:21

cylinder will go back to break this relay 2 we use the arrow 0 arrow 0 the address is 0.3 then this system will automatically move back and forth this part is ready next for the stop button stop the safety is 0.61 we activate using relay 3 stop we also turn off

7:02

for this stop, if the stop is pressed, the cylinder is minimal or the cylinder stops at a minimum, the only way is to break it here, in the relay start so that it doesn't automatically stop again, then the stop light is on, the stop light is on, the stop light is on, the stop light is on, the address is 100.03, stop, okay, it's okay, next is emergency, stop emergency,

7:43

emergency light emergency on, the emergency light is 60.02 then activate the emergency light which is 164 and the time-tested cylinder means we cut at the right angle we put the emergency light to cut here and here too and the pulsar too

8:26

0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0, 0,

9:03

the program is the way control W yes then we transfer the program by clicking control T ok yes yes ok yes ok the program has been transferred to the AC, let's just try it ok let's just operate it

9:43

what we have, the wiring that we have connected earlier, we immediately turn on the power supply first, here is the emergency button stop and start when we press start it will automatically go forward and reverse the cylinder will go forward and reverse automatically, we press start, it will go forward and reverse automatically, then we press stop, then the cylinder will stop at the minimum position and the stop light will turn on, the stop light

10:22

we press the start button again, the start on light, yes, because it will automatically go back to normal, then we press the emergency button, then it will stop for a moment where we press it, we release it, press it again, it stops for a moment and the emergency light also turns on, we release it, we stop, let's go,

11:02

That's our lesson today about the pneumatic cylinder control using PLC Omron. Thank you. Assalamualaikum warahmatullahi wabarakatuh.
